Mobile Communications - Reliable Connectors for Extreme Conditions | Telegärtner

Når kvalitet gjelder


Autorisert distributør av Telegärtner i Norge.

Telegärtner har spesialisert seg på mellom- og sluttprodukter for telekommunikasjon og datakommunikasjon for kunder med de mest krevende krav av høyteknologiske applikasjoner.

TINEX Group har lang fartstid med Telegärtner og kjenner deres produkter godt.


Kontakt oss i dag slik at vi kan hjelpe dere med riktig kvalitets produkter for 5G.




Reliable connectors for extreme conditions

Series adapters

No solution can fit everywhere. Applications and devices vary, and so too do connectors. Telegärtner bridges the gap between the various requirements and available connector types with a range of series adapters.


RRF connectors

Telegärtner are one of the leading manufacturers of RF connectors for mobile networks. With the 7-16, 4.3-10, N, 2.2-5 or NEX10 series coupled with simple but reliable solutions when connecting to cables from 1/4" to 1 5/8", excellent values in passive intermodulation can be achieved.


RF surge suppressors

TINEX offer a wide range of surge suppressors to protect electronic devices. Built into coaxial transmission lines, they suppress large electrical surges much like the ones that can be generated by lightning strikes in the immediate vicinity.



Jumper and RET cables


Telegärtner jumper cables have been tested in the harshest conditions and their outstanding transmission behavior has been confirmed by the independent testing laboratory TILAB. Our wide range includes all commonly used connector faces in the Cell IQ family (4.3-10, 2.2-5 and 1.5-3.5) as well as 7-16, NEX10 and N. They are available in standard lengths from 0.5 to 10 metres and custom lengths are available on request.

IP67 RET cables are available with AISG and/or D-Sub connectors and with halogen-free, flame-retardant and UV-stable cable sheaths. As they are manufactured to customer specifications, they are available in any length.





Terminating resistors

Terminating resistors are used to consume excess power and prevent reflections such as on unused ports or at the end of a cable. Terminating resistors can also be used to perform diagnostics on transmission lines, e.g. antenna masts. In addition to standard terminating resistors of up to 10 W with a wide range of connector faces, we offer low PIM terminating resistors of up to 200 W for PIM-sensitive applications such as passive DAS.



Autorisert distributør av Telegärtner i Norge.

Telegärtner har spesialisert seg på mellom- og sluttprodukter for telekommunikasjon og datakommunikasjon for kunder med de mest krevende krav av høyteknologiske applikasjoner.

TINEX Group har lang fartstid med Telegärtner og kjenner deres produkter godt.



Fiber to the Antenna







TOC RBC

The TOC RBC offers reliable protection against water and dust in applications that involve low mechanical stress. The flexible boot allows for easy cable routing for improved cable management even if limited space is available.


TOC FXC

Pluggable transceivers are not made for outdoor use. TOC FXC protects the connection of cables to transceivers and leaves enough space for the LC connector for a reliable connection at the same time.


TOC FEM

he fiber optic connection module TOC FEM is the ideal solution for changing outdoor cable to indoor cable as well as extending, separating and reconnecting existing lines or repairing damaged cables. The robust metal housing guarantees a safe and reliable connection, well protected from environmental or mechanical hazards.



4.3-10 MT series

Fibre optic connectors for powerful communication networks. Easy-to-install coaxial connectors designed for harsh environments with space constraints.



TOC TDC is the connector type for FTTA and broadband applications. Compact, robust and reliable, TOC TDC is easy to work with even in adverse conditions.



Together with Telegärtner we offers passive DAS components such as power splitters, directional couplers and tappers to maintain wireless coverage inside buildings. The range features a large selection of components that meet the need for a wide range of solutions for the drastically varying conditions of application sites.



  • A robust, scalable platform for cost-effective fiber and twisted pair expansion

  • The housing accepts modules of half and full height

  • The modules can be inserted from the front and fixed without tools



Many ports in a limited space, yet easy to handle – fiber optic patch panels reflect Telegärtner’s wealth of experience in a dynamic, demanding and developing field. Installers and users alike appreciate the robust design of these reliable patch panels, available in a large variety of standard and customer-specific designs.



  • 53% smaller than the 7-16 series

  • Extremely variable with the universal jack and three connector versions: screw, hand screw and push-pull

  • Compatible with numerous Semiflex, low-loss and corrugated cables measuring up to 1 5/8" as well as railway-approved cables



  • 53% smaller than the 4.3-10 series

  • Same installation dimensions as the TNC series

  • For indoor and outdoor applications

  • Screw, hand screw and push-pull-mechanisms available

  • For applications up to 20 GHz

  • For numerous cables from thin braid cables to 1/2" corrugated cables and railway-approved cables



  • Robust and PIM-stable design in the smallest space

  • 47% smaller than the 2.2-5 series based on the SMA-size

  • Screw and push-pull-mechanisms available

  • Compatible with cables up to 1/4"

  • Compatible with railway-approved cables



Les mer på Telegärtner sin egen webside: Trykk her


Kontakt oss på sales@tinexgroup.no eller 40 43 44 40 for mer informasjon
